.Built-in zoom camera and decoder, integrated structure, smart outline, Pan: ± 170°, Tilt: - 30° ~ + 90°
.Support YPbPr and HDMI Video Output
.Max. pan speed: 160°/s; Max. Tilt speed: 120°/s
.Support up to 255 presets
.Communications:RS232/RS422, Infrared remote-controlling
.Protocol: VISCA
.Image flip function (decided by camera module)
.Multifunctional IR remote controller
.Support terminals of video conference camera from other manufacturers
.Support top-down mounting
- .
| Monitor | Manual / time start-up setting |
| Preset speed | Pan 160°/s, Tilt 120°/s |
| Orientation precision | ± 0.05° |
| Rotation | Pan ± 170°; Tilt -30° ~ + 90° |
| Speed Proportion | Auto-adjust the speed as the length of focus |
| Preset | Controller support 9 presets, RS232 support 255 presets |
| Sync | Internal |
| Decoder | Built-in |
| Video output | RCA , S terminal |
| Remote controlling | RS422/232 |
| Baud rate(RS485) | 9600bps |
| Temperature | -10℃～+50℃ |
| Humidity | 0～95%（Non-condensation） |
| Dimension（L*W*H) | 138 * 138 * 163 mm |
| Power supply | DC 12V ± 1V |
| Power consumption | 12W |
| Weight | 1.2kg |
PDF document Télécharger
